Description of GEMINI - Digital die cutter for sheet labels

• he Gemini is an automatic sheet feeding and cutting system designed to automatically load and cut without the need of an operator.
  Equipped with a Graphtec CE7000 Plotter, cuts can be made on adhesive sheets, silk screen prints, shop material prints and digital prints on cardboard.

  With a newly designed ramp style loading tray and a wheel system, sheets can be automatically loaded into the plotter interruption free, cut, then dispensed into the catch tray all with ease.

  This plotter is equipped with integrated sensor reader to assist in reading the marks after each sheet is loaded all within a fraction of a second. This is done while working in tandem with the cutting management software resulting with a cut precision of 0.011".

  This innovative desktop cutter is capable of handling a variety of thickness and sheet sizes such as A4, A3, SRA3, SA3, Letter, Tabloid and Tabloid Extra.

  It also has the ability to do
  ✓ Perforation cuts (Small dots)
  ✓ Kiss cuts (Half cuts)
  ✓ Die cuts (Heavy cuts)
  ✓ Creasing
  for applications such as labels, business cards, shaped business cards, small boxes and more.

  It can successfully cut cardboard with a weight ranging 7.05 to 12.35 ounces (from 200 to 350 gr).



  Key features:


  - Uses industry best Graphtec CE6000 Plotter.
  - Compact design making it a desktop solution for a smaller workplace.
  - Automatic Ramp Style Feeder tray providing operator free job runs.
  - Proprietary software ensuring precise loading and cutting with excellent results.
  - Holds up to 150 sheets per job using sheet sizes (A4, A3, SA3, SRA3, Letter, Tabloid and Tabloid Extra).
  - Cutting options include: Die-Cut, Kiss-Cut, Perforation Cut and Media Creasing for boxes.
